Anchor Chain and Bend Stiffener Monitoring System for FPSO Integrity

The OceanTools ACABS-2 Anchor Chain Monitoring System has been designed in conjunction with a major FPSO designer for use on a new FPSO that will operate in Norwegian waters. The unit will typically be deployed after periods of heavy weather to check the integrity of the anchor chains.

Safe and reliable suction anchor
installation and removal

The Tritech AnchorZip 10 is a unique product
which has been developed using the highly
successful ZipPump and ZipJet technologies.
The AnchorZip 10 is a heavy duty suction anchor
pump designed for work-class vehicles able to
produce 25hp of hydraulic power.

Bathymetric & Oceanographic 센서

실시간 Altimeter, CTD 관측(Falmouth) 등 최대 4개 장비 장착 및 동시측정

수심: 700, 1400, 2000, 4000m

다중채널 echo sounder 탐사 및 파이프라인 탐사 병행 사용

FIowQuest 75 is an ultra long-range Acoustic Current ProfiIer manufactured by LinkQuest Inc., a company renown for its innovation, capability and product quality. The FlowQuest 75 current profiler is ideal for measuring currents and flows in deep oceans. With its capability for significantly longer range, and seamless integration with third-party sensors and LinkQuest acoustic modems, the FIowQuest system is not just a current profiler, It also serves a focal point for your deepwater deployments.

• 장거리 관측용 Acoustic Current Profiler
• 저렴한 비용과 신뢰성 높은 유향/유속 profiling
• Transponder(position), Acoustic Modem과 연동 가능
• Frequency: 150kHz
• 관측최대거리: 500m
• 관측최소거리: 2.8m
• 동작수심: 최대 6,000m
• 유속정확도: ±1%±5mm/s
• 최대관측유속: 20 knots
• 재질: Anodized Aluminum and Plastics
• 통신방법: RS422 or RS 232
• 메모리: 1Gbytes(표준) Compact Flash Card
• 길이: 25cm, 최대직경 40cm(센서)
• 무게: 13.6kg(수중)
• 기본장착센서: Compass, Tilt, Temperature
• 모니터링 소프트웨어 포함
